• Monitors : ECG, RESP, SPO2, dual-TEMP, NIBP, HR/PR. Optional ETCO2

• Application : OPD, ICUs, OTs, Wards ( Coronary Care Unit, Neonatal, Deptts. )

Technical Specifications :

• 12.1 inch High Resolution and High Brightness LCD Display. Audible and visual Alarm.
• Network connection : Expandable
• Power : AC 110~230V±10% 50/60Hz±2%. 90VA.
• Battery type :12V/2300mAH. Recharge time ≥5hour Use time < 3 hours
• Working Temp. 5℃～+40℃; Rel. humidity ≤85%; Atmospheric Pressure 700～1060hpa

Winning Advantages:

• TFT color LCD display. Li-battery.
• Four interface available: Standard screen / Big font / Oxygen screen / Multi-trends simultaneous displayed screen.
• Max. 256 hours trend graphs. All Parameters and Trends listed.
• Stores up to 1000 groups of NIBP data, HR/PR, TEMP, SPO2, RESP trends.
• Unique anti-defibrillation,anti-electrosurgical unit and weak perfusion monitor technology for SPO2
• Functions of Pacing analysis, ST Segment analysis, Abnormal Heart Rate analysis, Drug concentration calculations, Titration Table analysis.
